多环境部署实战：从单机到 Kubernetes 集群部署

前言
#

在生产环境中，我们通常需要管理多个部署环境：

开发环境（dev） - 开发者本地调试
测试环境（test） - QA 测试验证
预发布环境（staging） - 上线前最后验证
生产环境（prod） - 正式对外服务

每个环境都有不同的配置、资源限制和部署策略。本文将带你从零搭建一套完整的多环境部署体系，覆盖从单机 Docker Compose 到 Kubernetes 集群的完整方案。

环境规划
#

环境对比
#

环境	用途	资源	部署方式	更新频率
dev	本地开发调试	单机	Docker Compose	随时
test	自动化测试	2-3 节点	Docker Swarm	每日多次
staging	上线前验证	与 prod 一致	Kubernetes	每次发布前
prod	正式服务	多节点集群	Kubernetes	按需发布

配置差异
#

# 各环境配置对比
环境          副本数    CPU/内存     数据库       日志级别
dev           1        0.5C/512M    SQLite       DEBUG
test          2        1C/1G        MySQL        INFO
staging       2        2C/4G        MySQL 主从   INFO
prod          3+       4C/8G+       MySQL 集群   WARN

一、单机部署：Docker Compose 方案
#

1.1 项目结构
#

myapp/
├── docker/
│   ├── Dockerfile           # 应用镜像
│   └── nginx/
│       └── nginx.conf       # Nginx 配置
├── docker-compose.yml       # 基础配置
├── docker-compose.dev.yml   # 开发环境
├── docker-compose.test.yml  # 测试环境
├── docker-compose.prod.yml  # 生产环境
├── .env.dev                 # 开发环境变量
├── .env.test                # 测试环境变量
├── .env.prod                # 生产环境变量
└── app/
    └── ...                  # 应用代码

1.2 Dockerfile 编写
#

# docker/Dockerfile
FROM node:18-alpine AS builder

WORKDIR /app
COPY package*.json ./
RUN npm ci --only=production

COPY . .
RUN npm run build

# 生产镜像
FROM node:18-alpine

WORKDIR /app
COPY --from=builder /app/node_modules ./node_modules
COPY --from=builder /app/dist ./dist
COPY --from=builder /app/package.json ./

ENV NODE_ENV=production
EXPOSE 3000

USER node
CMD ["node", "dist/index.js"]

1.3 基础 docker-compose.yml
#

version: '3.8'

services:
  app:
    build:
      context: .
      dockerfile: docker/Dockerfile
    ports:
      - "3000:3000"
    environment:
      - NODE_ENV=${NODE_ENV:-development}
      - DATABASE_URL=${DATABASE_URL}
      - REDIS_URL=${REDIS_URL}
    depends_on:
      - db
      - redis
    networks:
      - app-network
    healthcheck:
      test: ["CMD", "wget", "-q", "--spider", "http://localhost:3000/health"]
      interval: 30s
      timeout: 10s
      retries: 3

  db:
    image: postgres:14-alpine
    environment:
      - POSTGRES_DB=${DB_NAME:-myapp}
      - POSTGRES_USER=${DB_USER:-myapp}
      - POSTGRES_PASSWORD=${DB_PASSWORD:-secret}
    volumes:
      - postgres-data:/var/lib/postgresql/data
    networks:
      - app-network

  redis:
    image: redis:7-alpine
    networks:
      - app-network

  nginx:
    image: nginx:alpine
    ports:
      - "80:80"
    volumes:
      - ./docker/nginx/nginx.conf:/etc/nginx/nginx.conf:ro
    depends_on:
      - app
    networks:
      - app-network

networks:
  app-network:
    driver: bridge

volumes:
  postgres-data:

1.4 环境差异化配置
#

开发环境（docker-compose.dev.yml）：

version: '3.8'

services:
  app:
    build:
      target: builder  # 使用开发镜像
    volumes:
      - ./app:/app/src  # 代码热重载
      - /app/node_modules
    environment:
      - DEBUG=true
      - LOG_LEVEL=debug
    command: npm run dev  # 开发模式启动

  db:
    ports:
      - "5432:5432"  # 暴露数据库端口

生产环境（docker-compose.prod.yml）：

version: '3.8'

services:
  app:
    deploy:
      replicas: 3
      resources:
        limits:
          cpus: '2'
          memory: 2G
        reservations:
          cpus: '1'
          memory: 1G
      restart_policy:
        condition: on-failure
        delay: 5s
        max_attempts: 3
    environment:
      - NODE_ENV=production
      - LOG_LEVEL=warn
    logging:
      driver: json-file
      options:
        max-size: "100m"
        max-file: "3"

  nginx:
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./ssl:/etc/nginx/ssl:ro  # SSL 证书

1.5 环境变量管理
#

.env.dev：

NODE_ENV=development
DATABASE_URL=postgresql://myapp:secret@db:5432/myapp
REDIS_URL=redis://redis:6379
LOG_LEVEL=debug
DEBUG=true

.env.prod：

NODE_ENV=production
DATABASE_URL=postgresql://myapp:${DB_PASSWORD}@prod-db:5432/myapp
REDIS_URL=redis://prod-redis:6379
LOG_LEVEL=warn
DB_PASSWORD=your-secure-password-here

1.6 部署命令
#

# 开发环境
docker-compose -f docker-compose.yml -f docker-compose.dev.yml --env-file .env.dev up -d

# 测试环境
docker-compose -f docker-compose.yml -f docker-compose.test.yml --env-file .env.test up -d

# 生产环境
docker-compose -f docker-compose.yml -f docker-compose.prod.yml --env-file .env.prod up -d

# 查看状态
docker-compose ps

# 查看日志
docker-compose logs -f app

# 重启服务
docker-compose restart app

# 清理资源
docker-compose down -v

二、Kubernetes 集群部署
#

2.1 集群规划
#

┌─────────────────────────────────────────────────────┐
│                  Kubernetes Cluster                  │
├─────────────────────────────────────────────────────┤
│  Namespace: dev     │  Namespace: test              │
│  ┌─────────────┐    │  ┌─────────────┐              │
│  │ app (1 副本) │    │  │ app (2 副本) │              │
│  │ db (SQLite)  │    │  │ db (MySQL)   │              │
│  └─────────────┘    │  └─────────────┘              │
├─────────────────────────────────────────────────────┤
│  Namespace: staging  │  Namespace: prod              │
│  ┌─────────────┐    │  ┌─────────────┐              │
│  │ app (2 副本) │    │  │ app (3+ 副本) │              │
│  │ db (主从)    │    │  │ db (集群)    │              │
│  └─────────────┘    │  └─────────────┘              │
└─────────────────────────────────────────────────────┘

2.2 Kubernetes 资源文件结构
#

k8s/
├── base/                    # 基础配置（所有环境共用）
│   ├── deployment.yaml
│   ├── service.yaml
│   ├── configmap.yaml
│   └── pvc.yaml
├── overlays/                # 环境差异化配置
│   ├── dev/
│   │   └── kustomization.yaml
│   ├── test/
│   │   └── kustomization.yaml
│   ├── staging/
│   │   └── kustomization.yaml
│   └── prod/
│       └── kustomization.yaml
└── scripts/
    └── deploy.sh

2.3 基础 Deployment
#

# k8s/base/deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
  labels:
    app: myapp
spec:
  replicas: 2
  selector:
    matchLabels:
      app: myapp
  template:
    metadata:
      labels:
        app: myapp
    spec:
      containers:
      - name: app
        image: myapp:latest
        ports:
        - containerPort: 3000
        env:
        - name: NODE_ENV
          valueFrom:
            configMapKeyRef:
              name: myapp-config
              key: NODE_ENV
        - name: DATABASE_URL
          valueFrom:
            secretKeyRef:
              name: myapp-secret
              key: DATABASE_URL
        resources:
          requests:
            cpu: "500m"
            memory: "512Mi"
          limits:
            cpu: "2000m"
            memory: "2Gi"
        livenessProbe:
          httpGet:
            path: /health
            port: 3000
          initialDelaySeconds: 30
          periodSeconds: 10
        readinessProbe:
          httpGet:
            path: /ready
            port: 3000
          initialDelaySeconds: 5
          periodSeconds: 5

2.4 Service 配置
#

# k8s/base/service.yaml
apiVersion: v1
kind: Service
metadata:
  name: myapp
  labels:
    app: myapp
spec:
  type: ClusterIP
  ports:
  - port: 80
    targetPort: 3000
    protocol: TCP
    name: http
  selector:
    app: myapp

2.5 ConfigMap 和 Secret
#

# k8s/base/configmap.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: myapp-config
data:
  NODE_ENV: "production"
  LOG_LEVEL: "info"
  API_TIMEOUT: "30000"

# k8s/base/secret.yaml
apiVersion: v1
kind: Secret
metadata:
  name: myapp-secret
type: Opaque
stringData:
  DATABASE_URL: "postgresql://user:password@db:5432/myapp"
  REDIS_URL: "redis://redis:6379"
  JWT_SECRET: "your-jwt-secret-here"

2.6 环境差异化配置（Kustomize）
#

开发环境（k8s/overlays/dev/kustomization.yaml）：

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

resources:
  - ../../base

namespace: dev

namePrefix: dev-

replicas:
- name: myapp
  count: 1

patchesStrategicMerge:
  - deployment-patch.yaml

configMapGenerator:
- name: myapp-config
  behavior: merge
  literals:
    - NODE_ENV=development
    - LOG_LEVEL=debug

开发环境补丁（k8s/overlays/dev/deployment-patch.yaml）：

apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
spec:
  template:
    spec:
      containers:
      - name: app
        resources:
          requests:
            cpu: "100m"
            memory: "256Mi"
          limits:
            cpu: "500m"
            memory: "512Mi"

生产环境（k8s/overlays/prod/kustomization.yaml）：

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

resources:
  - ../../base

namespace: prod

namePrefix: prod-

replicas:
- name: myapp
  count: 3

patchesStrategicMerge:
  - deployment-patch.yaml
  - hpa.yaml

configMapGenerator:
- name: myapp-config
  behavior: merge
  literals:
    - NODE_ENV=production
    - LOG_LEVEL=warn

生产环境补丁（k8s/overlays/prod/deployment-patch.yaml）：

apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
spec:
  template:
    spec:
      affinity:
        podAntiAffinity:
          preferredDuringSchedulingIgnoredDuringExecution:
          - weight: 100
            podAffinityTerm:
              labelSelector:
                matchLabels:
                  app: myapp
              topologyKey: kubernetes.io/hostname
      containers:
      - name: app
        resources:
          requests:
            cpu: "2000m"
            memory: "4Gi"
          limits:
            cpu: "4000m"
            memory: "8Gi"

2.7 水平自动扩缩容（HPA）
#

# k8s/overlays/prod/hpa.yaml
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: myapp-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: myapp
  minReplicas: 3
  maxReplicas: 10
  metrics:
  - type: Resource
    resource:
      name: cpu
      target:
        type: Utilization
        averageUtilization: 70
  - type: Resource
    resource:
      name: memory
      target:
        type: Utilization
        averageUtilization: 80

2.8 Ingress 配置
#

# k8s/overlays/prod/ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: myapp-ingress
  annotations:
    kubernetes.io/ingress.class: nginx
    nginx.ingress.kubernetes.io/ssl-redirect: "true"
    nginx.ingress.kubernetes.io/proxy-body-size: "50m"
    cert-manager.io/cluster-issuer: "letsencrypt-prod"
spec:
  tls:
  - hosts:
    - myapp.example.com
    secretName: myapp-tls
  rules:
  - host: myapp.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: myapp
            port:
              number: 80

三、自动化部署流水线
#

3.1 GitLab CI/CD 配置
#

# .gitlab-ci.yml
stages:
  - build
  - test
  - deploy

variables:
  DOCKER_REGISTRY: registry.example.com
  IMAGE_NAME: myapp

# 构建镜像
build:
  stage: build
  script:
    - docker build -t ${DOCKER_REGISTRY}/${IMAGE_NAME}:${CI_COMMIT_SHA} .
    - docker push ${DOCKER_REGISTRY}/${IMAGE_NAME}:${CI_COMMIT_SHA}
    - docker tag ${DOCKER_REGISTRY}/${IMAGE_NAME}:${CI_COMMIT_SHA} ${DOCKER_REGISTRY}/${IMAGE_NAME}:latest
    - docker push ${DOCKER_REGISTRY}/${IMAGE_NAME}:latest
  only:
    - main
    - develop

# 测试环境部署
deploy-test:
  stage: deploy
  script:
    - kubectl config use-context test-cluster
    - kubectl apply -k k8s/overlays/test/
    - kubectl rollout status deployment/test-myapp
  environment:
    name: test
    url: https://test.myapp.example.com
  only:
    - develop

# 预发布环境部署
deploy-staging:
  stage: deploy
  script:
    - kubectl config use-context staging-cluster
    - kubectl apply -k k8s/overlays/staging/
    - kubectl rollout status deployment/staging-myapp
  environment:
    name: staging
    url: https://staging.myapp.example.com
  only:
    - main
  when: manual

# 生产环境部署
deploy-prod:
  stage: deploy
  script:
    - kubectl config use-context prod-cluster
    - kubectl apply -k k8s/overlays/prod/
    - kubectl rollout status deployment/prod-myapp
  environment:
    name: production
    url: https://myapp.example.com
  only:
    - main
  when: manual
  needs:
    - deploy-staging

3.2 部署脚本
#

#!/bin/bash
# k8s/scripts/deploy.sh

set -e

ENV=${1:-dev}
NAMESPACE=$ENV

echo "🚀 开始部署到 ${ENV} 环境..."

# 选择集群上下文
case $ENV in
  dev)
    CONTEXT="dev-cluster"
    ;;
  test)
    CONTEXT="test-cluster"
    ;;
  staging)
    CONTEXT="staging-cluster"
    ;;
  prod)
    CONTEXT="prod-cluster"
    ;;
  *)
    echo "❌ 未知环境：$ENV"
    exit 1
    ;;
esac

# 切换集群
echo "📡 切换到集群：$CONTEXT"
kubectl config use-context $CONTEXT

# 创建命名空间（如果不存在）
echo "📦 检查命名空间：$NAMESPACE"
kubectl create namespace $NAMESPACE --dry-run=client -o yaml | kubectl apply -f -

# 应用配置
echo "⚙️  应用 Kubernetes 配置..."
kubectl apply -k k8s/overlays/${ENV}/ -n $NAMESPACE

# 等待部署完成
echo "⏳ 等待部署完成..."
kubectl rollout status deployment/${ENV}-myapp -n $NAMESPACE

# 检查服务状态
echo "🔍 检查服务状态..."
kubectl get pods -n $NAMESPACE -l app=myapp
kubectl get svc -n $NAMESPACE -l app=myapp

echo "✅ 部署完成！"
echo ""
echo "访问地址："
case $ENV in
  dev)
    echo "  http://localhost:3000"
    ;;
  test)
    echo "  https://test.myapp.example.com"
    ;;
  staging)
    echo "  https://staging.myapp.example.com"
    ;;
  prod)
    echo "  https://myapp.example.com"
    ;;
esac

四、配置管理最佳实践
#

4.1 敏感信息管理
#

❌ 不要这样做：

# 错误示例：明文密码
env:
  - name: DB_PASSWORD
    value: "super-secret-password"

✅ 正确做法：

# 使用 SealedSecrets（推荐）
kubeseal --format yaml < secret.yaml > sealed-secret.yaml
kubectl apply -f sealed-secret.yaml

# 或使用外部密钥管理
kubectl create secret generic myapp-secret \
  --from-literal=DATABASE_URL="postgresql://..." \
  --from-literal=JWT_SECRET="..." \
  -n prod

4.2 配置版本控制
#

# 使用 ConfigMap 版本
kubectl create configmap myapp-config-v1 \
  --from-literal=VERSION=1.0.0 \
  --from-literal=FEATURE_FLAG_A=true

4.3 环境变量继承
#

# 使用 Kustomize 的 configMapGenerator
configMapGenerator:
- name: myapp-config
  behavior: merge  # 合并而非替换
  literals:
    - NEW_FEATURE=enabled

五、监控与日志
#

5.1 Prometheus 监控
#

# k8s/base/servicemonitor.yaml
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: myapp
  labels:
    app: myapp
spec:
  selector:
    matchLabels:
      app: myapp
  endpoints:
  - port: http
    path: /metrics
    interval: 30s

5.2 日志收集
#

# 使用 Fluentd 收集日志
apiVersion: v1
kind: ConfigMap
metadata:
  name: fluentd-config
data:
  fluent.conf: |
    <source>
      @type tail
      path /var/log/containers/*.log
      pos_file /var/log/fluentd-containers.log.pos
      tag kubernetes.*
      read_from_head true
      <parse>
        @type json
      </parse>
    </source>

六、常见问题
#

Q1: 如何在不同环境使用不同的数据库？
#

答：使用 Secret 管理不同环境的数据库连接：

# 开发环境 - SQLite
kubectl create secret generic myapp-secret -n dev \
  --from-literal=DATABASE_URL="sqlite:///app.db"

# 生产环境 - MySQL 集群
kubectl create secret generic myapp-secret -n prod \
  --from-literal=DATABASE_URL="mysql://user:pass@prod-mysql:3306/myapp"

Q2: 如何快速回滚？
#

答：使用 Kubernetes 的回滚命令：

# 查看历史版本
kubectl rollout history deployment/prod-myapp -n prod

# 回滚到上一个版本
kubectl rollout undo deployment/prod-myapp -n prod

# 回滚到指定版本
kubectl rollout undo deployment/prod-myapp -n prod --to-revision=2

Q3: 如何灰度发布？
#

答：使用 Istio 进行流量管理：

apiVersion: networking.istio.io/v1alpha3
kind: VirtualService
metadata:
  name: myapp
spec:
  hosts:
  - myapp.example.com
  http:
  - route:
    - destination:
        host: myapp
        subset: v1
      weight: 90
    - destination:
        host: myapp
        subset: v2
      weight: 10

总结
#

多环境部署的核心原则：

配置分离 - 代码与环境配置完全解耦
渐进式部署 - dev → test → staging → prod
自动化 - CI/CD 流水线自动部署
可回滚 - 快速回滚机制
可观测 - 完善的监控和日志

关键收获：

✅ Docker Compose 适合单机和开发环境
✅ Kubernetes 适合生产环境和高可用需求
✅ Kustomize 管理环境差异化配置
✅ CI/CD 实现自动化部署
✅ Secret 管理敏感信息

相关资源：

下一篇： 《Kubernetes 生产环境调优实战》

前言 #

环境规划 #

环境对比 #

配置差异 #

一、单机部署：Docker Compose 方案 #

1.1 项目结构 #

1.2 Dockerfile 编写 #

1.3 基础 docker-compose.yml #

1.4 环境差异化配置 #

1.5 环境变量管理 #

1.6 部署命令 #

二、Kubernetes 集群部署 #

2.1 集群规划 #

2.2 Kubernetes 资源文件结构 #

2.3 基础 Deployment #

2.4 Service 配置 #

2.5 ConfigMap 和 Secret #

2.6 环境差异化配置（Kustomize） #

2.7 水平自动扩缩容（HPA） #

2.8 Ingress 配置 #

三、自动化部署流水线 #

3.1 GitLab CI/CD 配置 #

3.2 部署脚本 #

四、配置管理最佳实践 #

4.1 敏感信息管理 #

4.2 配置版本控制 #

4.3 环境变量继承 #

五、监控与日志 #

5.1 Prometheus 监控 #

5.2 日志收集 #

六、常见问题 #

Q1: 如何在不同环境使用不同的数据库？ #

Q2: 如何快速回滚？ #

Q3: 如何灰度发布？ #

总结 #
